ALTA NX
BRIOT ALTA NX
Prestigious finishes
The ALTA NX pushes back the limits of grinding, while optimizing your time. It allows the most delicate work: the creation of drilled mounts and the grinding of lenses with a strong base finally become accessible.
“Autofocus” bevels
To customize and optimize your mount, you have four fully automatic bevels that take into account the characteristics of the lens and the 5D shape of the frame.
“Finesse” counter-bevel
Surgical precision on the internal and external faces of the lens, whatever its thickness.
“Millimeter” drilling
Thanks to a unique design, the drilling module makes it easy to achieve an inclination ranging from 0 to 30°, with a precision of 1/10th of a millimeter: the lens adapts immediately to the frame. Now, you can do at home, at a lower cost and with better quality, what you previously outsourced.
“Concordance” Grooving
The inclined groove is automatically positioned according to the curvature and thickness of the glass.
“Diamond” Polish Absolute transparency and brilliance to perfect the elegance of your assemblies.
High-end sobriety
The ALTA NX also stands out for its completely original design and refined aesthetics. A compact machine, whose rounded shapes and delicate colors would almost make you forget that your workshop is a workplace!
Let yourself surf!
Thanks to the innovative ergonomics of the ALTA NX, you will experience new visual and tactile sensations. The 3D pictograms, finely developed for greater ease, allow you to navigate with complete peace of mind.
An ideal interface
The icons, extremely readable, show you the glass as it is once the finishing
is completed. In addition, messages of advice, attention, and error allow to guide you throughout the grinding.
The strong points
▪ It takes up little space.
▪ It performs very high-quality finishes.
▪ It gives your work real added value.
▪ It allows you to perform the most complex tasks with complete simplicity.
▪ It always gives you the opportunity to intervene, even if its functions are automatic.
▪ Grinder available with or without drilling.
Technical Specifications:
Briot Alta Nx
| Parameter | Value |
|---|---|
| Dimensions | |
| Width | 510 mm |
| Depth | 615 mm |
| Height | 570 mm |
| Weight | 69 kg |
| Pump Section Outlet | Power available (for the pump) = 450 W |
| Maximum water pressure | 2 – 7 bars (pH 7 – 7.5) |
| Controls/mains insulation | Stepped up |
| Noise level | 72 dB |
| Degree of pollution | 2 |
| Installation Category | II |
| Ambiant temperature | 13° C to 35° C |
| Relative Humidity | 10% to 80% |
| Maximum altitude | 2,000 m |
| Electrical Specifications | |
| 230 V – 50 Hz | |
| Input voltage | 200 V – 250 V |
| Power consumption | 7 A |
| Electric power | 1600 W |
| Fuses | F1 and F2 = 10 AT Littelfuse 32606, F3 = 3,15 AT Littelfuse 2183-15, F4 and F5 = 3,15 AT Littelfuse 2183-15, F6 = 8 AT Littelfuse 218008 |
| 115 V – 60 Hz | |
| Input voltage | 120 V -125 V |
| Power consumption | 14 A |
| Electric power | 1600 W |
| Fuses | F1 and F2 = 25 AT Ferraz 125 V SA 6,3×32 Réf. T84 427, F3 = 5 AT Ferraz 250 V 5ST 5×20, F4 and F5 = 5 AT Ferraz 250 V 5ST 5×20, F6 = 8 AT Littelfuse 218008 |
| Standards | |
| 230 V – 50 Hz | |
| Meets Di 2006/95/CEE (electric) safety directives | |
| IEC 61010-1 | |
| 115 V – 60 Hz | |
| ETL marking | UL 61010 – 1, CAN/CSA C22.2 N°61010 – 1 |
I wanted to know if all the calibration tools as well as accessories were available for each piece of equipment
This list is purely informative and in no way reflects reality. Please check the presence of the accessories in the photos below. No claim will be accepted. For more information you can consult the website
Do the photos correspond to the reference above or are they generic?
The photographs illustrating the products are contractual pictures. Photos are taken for each machine: each picture and each video are REAL ones.
Are your machines perfectly functional? And calibrated ready to cut?
The best machines and only “one first owner” models before, are choosen for being renovated process. Then, they are fully refurbished by our qualified technicians, and calibrated here in Montluçon, middle France. The products sold by SARL Digital Screen System are Second Hand market, so we encourage our customers to make an educated decision, take responsibility, and to remember that it’s still pre-owned ones, aesthetically and mechanically.
